Customized Alloy Steel Headers And Manifolds ASME Standard Red Painted

Customized Alloy Steel Headers And Manifolds ASME Standard Red Painted

MOQ: 1 Set / Sets 10tons
Price: Negotiable
Standard Packaging: Seaworthy Packing
Delivery Period: 50 Days
Payment Method: L/C, T/T, Western Union
Supply Capacity: 500 Tons per month
Detail Information
Place of Origin
China
Brand Name
HD Boiler
Certification
ISO9001 , SGS , TUV , ASME , EN
Model Number
Boiler Manifold
Material:
Alloy Steel
Dimension:
Customized
Standard:
ASME Standard
Port:
Shanghai
Condition:
New
Color:
Red Painted
Highlight:

Alloy Steel boiler header manifolds

,

Red Painted boiler header manifolds

,

Alloy Steel red boiler Manifolds

Product Description



Customized Alloy Steel Headers And Manifolds ASME Standard Red Painted





Product Description



1.The headers of boilers include water-cooling hinders of boilers proper, economizer hinders, superheater hinders, etc.

2.They function for gathering, mixing and redistribution in boiler systems. In structure, they include end cover hinders or necking hinders.

II. Product Description

1.In manufacturing, the key of end cover hinder is welding. Since by manual arc welding, the weld joint is single-side welding without quality guarantee at the ends.

2. In addition, due to large welding workload, frequent return for repair and long working period, it became the throat process of the whole hinder production.

3.When making hinders of the style, we adopt advanced production technique, complete large equipment and mature technology, especially automatic submerged arc welding between hinders and end covers. 4.Such welding methods have high manufacturing efficiency, good quality, beautiful welding shape, safety, reliability, etc.

1.The necking hinders of the Company are made by hot press and retracting of seamless steel pipes at special hinder necking machine.

2. In this way, the hinders will have thicker walls and cleaner surface. The necking cover will form membrane stress rather than bending stress with desired stress performance under the effect of inner pressure.

3.Many boiler factories have made stress test and bursting test.

4. The tests have reached the same conclusion: the stress in end cover wall under working pressure is far lower than permissible stress of the material.

5.The bursting pressure is over 20 times the working pressure during cold blasting.

6.Without end cover, necking hinders have welding seams, large strength margin, high hinder pressure as well as safe and reliable performance.

7.As a result, necking hinders are very popular among the manufacturers and users.
8.Checking hand holes of the hinders have welding style and mobile style.


III. Material

Hinder proper (of large-diameter seamless steel pipes), end covers, pipe joints, hand holes, thermometer jack, etc. During manufacturing, welding test is conducted strictly in line with welding technique to ensure 100% quality.

IV. Performance features
Excellent in welding quality, highly automatic, safe and reliable.



Warranty and after-sale service



HDB promises the top quality of every set of machine and best after-sales service as followings :


(A) The boiler body guarantee is two years , for accessories three years
(B) During the guarantee period , if the main body defective or broken without wrong operating , HDB must replace the parts for free or prepare the spare-parts for free.
(C)

HDB should provide boiler technical service and operation guidance for whole life long.

(D)

Regarding to the installation and training , the buyer should take all the correlative charges (accommodation and food , round -trip tickets)



How's Quality Control


1 Strength calculation report with applied materials information;
2 100%NDT(non-destructive inspection) report of steel plate, tube and welding rod;
3 100%X-ray inspection report (welding seam): to ensure the quality of the entire boiler;
4 Hydraulic test report: ensure the standard working pressure and safety



Customized Alloy Steel Headers And Manifolds ASME Standard Red Painted 0
