High Efficient Hrsg Steam Generator Customized Waste Heat Recovery Steam Generator
Product Details
| Certification: | SGS,ASME,EN | Dimension(l*w*h): | Cylinder,Customziation,1030*550*1450 Or Customized |
|---|---|---|---|
| Weight: | Customized,88-260kg,Specifications | Product Name: | HRSG Heat Recovery Steam Generator,Automatic Steam Generator |
| Material: | ALLOY,Q345R Steel Plate,Steel | Surface Treatment: | Painted |
| Highlight |
waste heat recovery boiler,industrial boilers and heat recovery steam generators |
||
Product Description
Professional High Efficient Customized Alloy HRSG Heat Recovery Steam Generator
Description
Times are changing.Our cogeneration industry has experienced from scratch,small to large development process with recycling economy,sustainable development,energy conservation and low-carbon economy ideas put forward one by one.Significant progress has been made in using the waste process heat in cement plants. But the use of this process heat to generate electricity fell during past years, which saw low and steady power prices. Deregulation is bringing the specter of extremely volatile electricity prices, loss of control over power costs, and the real likelihood that energy prices may increase in the near term in some areas.
Features
Kiln (AQC) HRSG Features
1, Modular assembly structure, reliable sealing expansion
2, Adopt wear fin tubes, boiler pressure parts life assurance
3, Unique flash technology, the boiler outlet temperature is reduced to below 90ºC
Kiln (SP) HRSG Features
1, Heating surface tubes and headers with privildged connection structure, reducing mechanical shock and vibration
2, By mechanical vibration cleaning mode, continous cleaning mode little impact on system operation
3, Set sealed scraper gray machine, greatly reducing dust tail.
Advantages
|
|
|
|
|
Parameter
| Cement production line capacity t/d | 2500 | 3500 | 5000 | |
| Boiler inlet flow (Nm3/h) | Kiln(front) | 96800 | 142000 | 192000 |
| Kiln(tail) | 173000 | 241000 | 369000 | |
| Boiler inlet gas temperature℃ | Kiln(front) | 380 | 420 | 395 |
| Kiln(tail) | 365 | 360 | 355 | |
| Rated evaporation t/h | Kiln(front) | 2/9.6 | 3/17 | 3.2/21.3 |
| Kiln(tail) | 4.2/16.2 | 5.3/23 | 10.5/32 | |
| Rated steam pressure Mpa | Kiln(front) | 0.2/2.4 | 0.2/2.4 | 0.2/2.4 |
| Kiln(tail) | 0.2/2.4 | 0.2/2.4 | 0.2/2.4 | |
Company Information
Hua Dong Boiler Co., Ltd. is a high-tech enterprise specialized in manufacturing boilers. Established in early 1985s, has two manufacturing bases, this company covers 400,000 ㎡ with fixed assets amounting to USD 110,000,000. There are 1100 employees including 150 technicians and 600 coded welders. Hua Dong holds the manufacturing licenses for Grade A boilers and Grade A1&A2 pressure vessels issued by Chinese General Administration of Quality Supervision, Inspection and Quarantine; also it holds the "S" and "U" "NB" stamps issued by American Society of Mechanical Engineers; meanwhile, this Company has passed the certification of ISO9001, SO3834, EN12952 Quality Management System.
Design and development
Collect all parameters for product design, make design acording to the Supervisory Regulations on Boiler Safety Technology, other laws, rules, regulations and professional standards, and 100% meet the product standards and customers' requirements.
Manufacturing equipment
- Our products' quality is ensured by advanced, excellent facilities and manufacturing equipment.
- We have introduced 400 sets of advanced processing and inspection equipment, including plasma cutting machine, NC drilling equipment, automatic welding system, welding equipment and real-time online imaging detection system, etc., which successfully ensure excellent quality of our products.
