Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired

Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired

  • Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired
  • Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired
  • Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired
  • Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired
Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired
Product Details:
Place of Origin: Zhangjiagang,Jiangsu,China
Brand Name: HD Boiler
Certification: ISO9001,ASME,Grade A,SGS,EN,TUV
Model Number: CFB Boiler
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Seaworthy Packing
Delivery Time: Negotiation
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Sets /Year
Contact Now
Detailed Product Description
Condition: New Structure: Fire Tube
Fuel: Coal-Fired Water Circulation: Natural Circulation
Pressure: High Pressure Range Of Applications: Power Station
Specification: Customized Place Style: Vertical
Burning StylBurning Style: Fluidized Bed Furnace Installation: Bulk Boiler
High Light:

circulating fluidized bed boilers

,

utility boiler

Long life thermal efficiency CFB Boiler Circulating Fluidized Bed Hot Water Boiler for Utility ASME



Product Description


Circulating fluidized bed is of low-temperature combustion, therefore, nitrogen oxides emissions of such boiler is much lower than that of coal-powder boiler, and such boiler could directly desulfurized during combustion process. Circulating fluidized bed boiler with high desulfurization rate is economical.
Circulating fluidized bed boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.



Structure Features



HD boilers are efficient, energy saving and environmental friendly, which can help power plants actualize low pollutant emission based on their advanced technology and reliable running.

High efficiency: combustion efficiency 96~99%, carbon content in ash only about 2%, efficiency of boiler reaches 85%.
- Suitable for various kinds of coal.
- Load can be adjusted in the range of 25%~110%, average 5% in one minute.
- Clean combustion and environment friendly.
- Use lime stone mixed into the fuel for desulfuration, rate up to 84%.
- NOx emission capacity can be controlled to 150ppm or less.
- Ash with low carbon content can be used for cement or construction materials.



Parameter



Model Capacity (t/h) Pressure(MPa) Steam temperature (ºC) Feed water temperature
(ºC)
Desulfurization efficiency
HD-35/3.82-M 35 3.82 450 150 min 82
HD-35/5.3-M 35 5.3 450 150 min 82
HD-75/3.82-M 75 3.82 450 150 min 82
HD-75/5.3-M 75 5.3 485 150 min 82
HD-75/9.8-M1 75 9.8 540 215 min 82
HD-130/3.82-M 130 3.82 450 172 min 82
HD-130/5.3-M 130 5.3 485 172 min 82
HD-130/9.8-M 130 9.8 540 215 min 82

Fuel:soft/lean/bituminou coal, anthracite,lignite,biomass and etc.



Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired 0



Certifications


Thermal Efficiency CFB Circulating Fluidized Bed Boilers , Hot Water Boiler Coal Biomass Fired 1



Company Information


HD Boiler established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port or 60km State Road to Suzhou or Wuxi, with transportation extending in all directions conveniently and quickly.
