    Product Details:

    Place of Origin: China
    Brand Name: HD Boiler
    Certification: ISO9001 , SGS , TUV , ASME , EN
    Model Number: Superheater and Reheater

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set
    Price: Negotiable
    Packaging Details: Seaworthy Packing
    Delivery Time: 30 Days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 1500 Tons / Month
    Contact Now
    Detailed Product Description
    Condition: New Fuel: Coal/Gas/Oil-fired,Water Heat
    Type: Natural Circulation Pressure: Low/High Pressure
    Range Of Applications: Industry/Power Station Specification: Customized
    High Light:

    convection superheater

    ,

    reheater in power plant

    Heat Efficiency Improving Boiler Parts Superheater Coils ASME Standard For Power Station



    Product Description:



    Superheater

    Fossil fuel power plants often have a superheater section in the steam generating furnace.The steam passes through drying equipment inside the steam drum on to the superheater, a set of tubes in the furnace. Here the steam picks up more energy from hot flue gases outside the tubing, and its temperature is now superheated above the saturation temperature.



    Reheater

    Power plant furnaces may have a reheater section containing tubes heated by hot flue gases outside the tubes. Exhaust steam from the high-pressure turbine is passed through these heated tubes to collect more energy before driving the intermediate and then low-pressure turbines.





    1 Material composition Carbon steel, alloy steel or heat-resistant steel, collection boxes and other supporting material. Tubes are customized types of specifications.
    2 Design pattern Vertical or horizontal layout.
    3 Advantages Beautiful appearance, size, accuracy, first-class bending and welding technology, first-class detection equipment.





    Type Advantages Disadvantages Supporting method:


    Pendant-type 1.Firm structural support

    1. Flow blockage by condensed steam

    2. Needs slow restart to purge the water that accumulates in the bottom. supported from above


    Inverted-type 1.Proper drainage of the condensed steam

    1. Lack the structural rigidity, especially in high speed gas flow Supported from below



    Horizontal -type

    1. Proper drainage

    2. Good structural rigidity.



    They do not view the flam directly so they are mainly from the convective type Usually supported in the vertical gas ducts parallel to the main furnace.



    Heat Efficiency Improving Boiler Parts Superheater Coils , ASME Standard 0

    Heat Efficiency Improving Boiler Parts Superheater Coils , ASME Standard 1

    Design structure

    1. heating saturated steam, temperature up to 900 degree C.



    2. high efficiency, >90%.



    3. high speed heating.



    4. design with stainless steel.



    5. long design service life, 15 years.



    Send us required technical data, such as steam capacity, presure, required temperature etc. We will design accordingly.





    HD Boiler offers a best in class facility,including

    • Fabrication area of 200,000 square meters
    • 150 Engineers
    • 600 Coded welders
    • 60 Licensed Inspectors (including NDT level-lll instructors)
    • Grade-ALicenses for Design and Manufacture boiler (issued by the State Administration of Quality Supervision and Inspection)
    • ISO 90001:2008 Quality System
    • ASME Certificate of Utility Boiler
    • ASME‘S’ , ‘U’ and NB stamp authorization
