High Frequency Welding Spiral Helix Wrapped Fin Tube Heat Exchanger Stainless Steel

High Frequency Welding Spiral Helix Wrapped Fin Tube Heat Exchanger Stainless Steel

MOQ: 1 Set
Price: Negotiable
Standard Packaging: Iron Frame Packing
Delivery Period: 30 - 60 Days
Payment Method: L/C, T/T, Western Union, MoneyGram
Supply Capacity: 500 Tons Per Month
Detail Information
Place of Origin
China
Brand Name
HD Boiler
Certification
ISO9001,ASME,Grade A,SGS,EN
Model Number
Fin Tube
Condition:
New
Pressure:
Low / High Pressure
Range Of Applications:
Power Station
Specification:
Customized
Function:
Heat Exchanger
Fuel:
Coal
HS Code:
3215960855
Port:
Shanghai , China
Highlight:

spiral fin tube

,

heat exchanger fin tube

Product Description

Stainless steel Heating area High Frequency Welding Spiral Helix wrapped Fin Tube Heat Exchanger



Product Description



H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer, which has high efficiency,little resistance,less wear and light weight.



Technical Parameters



Item Base Tube O.D
(mm)
Base Tube Thickness (mm) Fin Height (mm) Fin thickness(mm) Fin Pitch(mm)
Range 25.4 mm ~1600mm 2.5 mm ~40 mm 0.5 mm ~20.0 mm 0.5 mm ~3.0 mm 5 mm ~ 25.4 mm
Material Carbon Steel,Alloy Steel,Stainless Steel
Length 0<L≤ 12000



Principle



• H fin tube is a kind of boiler parts, to have two steel circular symmetry to be welded on fluorescent tubes to form fins positive shap much like letter "H", so called H-fin tube. H-economizer widely used in utility boilers, industrial boilers, marine power, such as the tail of heat exchanger components.

H-economizer two rectangular fin, similar to a square, its edge length for the fluorescent tubes of 2-fold, an expansion of the heating surface.

H-economizer flash resistance welding processes used, the welding seam after the high rate of fusion, weld tensile strength, and has good thermal conductivity. H-economizer can also manufacture dual tube "double H" type fin tubes, its rigid structure, and can be applied to a longer tube row occasion.



High Frequency Welding Spiral Helix Wrapped Fin Tube Heat Exchanger Stainless Steel 0



Certificate



High Frequency Welding Spiral Helix Wrapped Fin Tube Heat Exchanger Stainless Steel 1



Company Indroduction



Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.



1. Fabrication area of 200,000 square meters

2. 150 Engineers

3. 600 Coded welders

4. 60 Licensed Inspectors(NDT Level-III instructors)

5. Class-A Licenses for Design and Manufacture Boiler

6. ISO 9001:2008 Quality System

7. ASME Certificate of Power Boilers

8. ASME 'S','U' and NB stamp authorization
