Hot Water CFB Boiler Circulating Fluidized Bed High Desulfurization Rate ASME standard
Product Details
| Condition: | New | Structure: | Fire Tube |
|---|---|---|---|
| Fuel: | Coal-Fired | Water Circulation: | Natural Circulation |
| Pressure: | High Pressure | Range Of Applications: | Power Station |
| Specification: | Customized | Place Style: | Vertical |
| Burning StylBurning Style: | Fluidized Bed Furnace | Installation: | Bulk Boiler |
| Highlight |
circulating fluidized bed boilers,coal fired boiler |
||
Product Description
High Desulfurization Rate Hot Water CFB Boiler Circulating Fluidized Bed ASME standard
Product Description
Circulating fluidized bed is of low-temperature combustion, therefore, nitrogen oxides emissions of such boiler is much lower than that of coal-powder boiler, and such boiler could directly desulfurized during combustion process. Circulating fluidized bed boiler with high desulfurization rate is economical.
Circulating fluidized bed boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.
Structure Features
HD boilers are efficient, energy saving and environmental friendly, which can help power plants actualize low pollutant emission based on their advanced technology and reliable running.
High efficiency: combustion efficiency 96~99%, carbon content in ash only about 2%, efficiency of boiler reaches 85%.
- Suitable for various kinds of coal.
- Load can be adjusted in the range of 25%~110%, average 5% in one minute.
- Clean combustion and environment friendly.
- Use lime stone mixed into the fuel for desulfuration, rate up to 84%.
- NOx emission capacity can be controlled to 150ppm or less.
- Ash with low carbon content can be used for cement or construction materials.
Parameter
| Model | Capacity (t/h) | Pressure(MPa) | Steam temperature (ºC) | Feed water temperature (ºC) |
Desulfurization efficiency |
| HD-35/3.82-M | 35 | 3.82 | 450 | 150 | min 82 |
| HD-35/5.3-M | 35 | 5.3 | 450 | 150 | min 82 |
| HD-75/3.82-M | 75 | 3.82 | 450 | 150 | min 82 |
| HD-75/5.3-M | 75 | 5.3 | 485 | 150 | min 82 |
| HD-75/9.8-M1 | 75 | 9.8 | 540 | 215 | min 82 |
| HD-130/3.82-M | 130 | 3.82 | 450 | 172 | min 82 |
| HD-130/5.3-M | 130 | 5.3 | 485 | 172 | min 82 |
| HD-130/9.8-M | 130 | 9.8 | 540 | 215 | min 82 |
Fuel:soft/lean/bituminou coal, anthracite,lignite,biomass and etc.
Certifications
Company Information
HD Boiler established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port or 60km State Road to Suzhou or Wuxi, with transportation extending in all directions conveniently and quickly.
