Special construction technology Biomass Fuel Steam Boiler Natural circulation boiler TUV
Product Introduction
This boiler adopt chain grate,suitable for molding pellet fuel,can add a small amount of wood,wood block,also can burn with coal.
This boiler adopt the newest achievements in scientific research, such as:Arched Tube plate, thread smoke tube etc, solve the tube plate crack of shell type boiler, Water wall tube burst, low efficiency, insufficient of power,Poor pf coal type adaptability etc.
Features
1. Durable and Long life time.
2. Enough steam output, less heat dissipation, high thermal efficiency, lowest coal consumption.
3. 90% min high efficiency dust collector, more Eco-friendly.
4. Full automatic control, Protection devices for overheating, over-pressure, lacking water, leak detection, flame-out
5. Automatic fuel feeding, automatic water feeding, automatic ash remove so on.
Parameter
| Parameter | Unit | DZL1-0.7 | DZL2-0.7 | DZL4-1.25 | DZL6-1.25 | DZL8-1.6 | DZL10-1.6 | DZL15-1.6 |
| Rated steam output | t/h | 1 | 2 | 4 | 6 | 8 | 10 | 15 |
| Fixed pressure | Mpa | 0.7 | 0.7 | 1.25 | 1.25 | 1.6 | 1.6 | 1.6 |
| Fixed vapor temperature | °C | 170 | 170 | 194 | 194 | 204.3 | 204.3 | 204.3 |
| Water temperature | °C | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Fuel | coal, biomass, straw pellet, rice husk so on | |||||||
| Thermal eficiency | % | 80 min | ||||||
| Gross weight | t | 13.5 | 18.5 | 23 | 35 | 46 | 58 | 83 |
Advantages
1). No need special protection when power off.
2). Higher efficiency, heating fast.
3). Safe and Realiable.
4). Easy to install.
Certifications
Company Information
HD Boiler established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port or 60km State Road to Suzhou or Wuxi, with transportation extending in all directions conveniently and quickly.
|
|
