Professional Power Station CFB Boiler / Steam Hot Water Boiler Low Nitrogen Oxides Emission
Product Details
| Model: | Cfb Boiler | Fuel: | Coal - Fired |
|---|---|---|---|
| Function: | Steam Boiler | Media: | Steam And Water |
| Drum Placement: | Vertical Boiler | Manufacturing Level: | A |
| Usage: | Power Station | Burning Style: | Fluidized Bed Furnace |
| Condition: | New | Port: | Shanghai |
| Highlight |
circulating fluidized bed boilers,coal fired boiler |
||
Product Description
China Professional Boiler Manufacturer CFB Boiler for Power Station High Efficency Low nitrogen oxides emission
Features
• High thermal efficiency can reach up to 95%-99%.
• Low NOx emission by low carbon burning.
• Advanced technology in boiler abrasion resistance.
• Long service life and reliable & easy operation.
Product Introduction
China professional boiler manufacture CFB boiler for power station is of low-temperature combustion, therefore, nitrogen oxides emissions of such boiler is much lower than that of coal-powder boiler, and such boiler could directly desulfurized during combustion process. CFB boiler for power plant with high desulfurization rate is economical.
Our China professional boiler manufacture CFB boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.
The ash of CFB boiler is of high activity, thus it is easy to realized comprehensive utilization without secondary pollution.
Parameter
| Model | Capacity (t/h) | Pressure(MPa) | Steam temperature (ºC) |
Feed water temperature (ºC) |
Desulfurization efficiency |
| HD-35/3.82-M | 35 | 3.82 | 450 | 150 | min 82 |
| HD-35/5.3-M | 35 | 5.3 | 450 | 150 | min 82 |
| HD-75/3.82-M | 75 | 3.82 | 450 | 150 | min 82 |
| HD-75/5.3-M | 75 | 5.3 | 485 | 150 | min 82 |
| HD-75/9.8-M1 | 75 | 9.8 | 540 | 215 | min 82 |
| HD-130/3.82-M | 130 | 3.82 | 450 | 172 | min 82 |
| HD-130/5.3-M | 130 | 5.3 | 485 | 172 | min 82 |
| HD-130/9.8-M | 130 | 9.8 | 540 | 215 | min 82 |
Fuel:soft/lean/bituminou coal, anthracite,lignite,biomass and etc.
Company Introduction
Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
1. Fabrication area of 200,000 square meters
2. 150 Engineers
3. 600 Coded welders
4. 60 Licensed Inspectors(NDT Level-III instructors)
5. Class-A Licenses for Design and Manufacture Boiler
6. ISO 9001:2008 Quality System
7. ASME Certificate of Power Boilers
8. ASME 'S','U' and NB stamp authorization
Product Highlights
China Professional Boiler Manufacturer CFB Boiler for Power Station High Efficency Low nitrogen oxides emission Features • High thermal efficiency can reach up to 95%-99%. • Low NOx emission by low carbon burning. • Advanced technology in boiler abrasion resistance. • Long service life and reliable ...
