5T -130T Waste Heat HRSG Heat Recovery Steam Generator Water Tube Boiler
Product Details
| Condition: | New | Structure: | WHRS Type |
|---|---|---|---|
| Fuel: | Biological | Pressure: | Low/High Pressure |
| Range Of Applications: | Industrial | Specification: | Customized |
| Manufacturing Level: | A | Surface Treatment: | Painted |
| Output: | Steam | Water Circulation: | Natural Circulation |
| Highlight |
waste heat recovery steam generator,waste heat recovery boiler |
||
Product Description
High thermal efficient 5t-130t Waste Heat Water Tube Boiler HRSG Waste Heat Recovery Boiler
Production
Waste heat boiler is comprehensive utilization heat auxiliary equipment, which is generally installed in the flue gas pass, absorb heat (or waste heat) of exhausting flue gas to generate steam, and to reduce flue gas temperature.
Waste heat boilers have the following characteristics
1. Thermal load instability, will change as the production cycle.
2. Large amount of dust in the flue gas.
3. Gas is corrosive.
4. Installation of waste heat boiler will be subject to site conditions, there is also how the co-ordination with the front-end process and so on.
And the present stage,we can provide kinds of HRSG boiler as belows:
- Municipal solid waste incinerator(MSWI)
- Straw burning boiler
- Biomass Boilers
- Waste heat recovery unit gas turbine
- Low temperature HRSG boiler for dry cement kiln
Waste heat boiler system process description
Drum → down-comer → tube row heat surface → riser → drum(water consumption after the feed pump to add water)
Packaging: our products have standard export package, fumigated wood box, U-steel, steel frame reach to sea transportation requirement.
Shipping: we have our own professional shipping company, make sure the product arrived your destination safely and as soon as possible.
Company Introduction
Established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port
