Place of Origin: | China |
Brand Name: | HD BOILER |
Certification: | ISO9001,ASME,Grade A,SGS,EN |
Model Number: | superheater |
Minimum Order Quantity: | 1 Set/Sets 10tons |
---|---|
Price: | Negotiable |
Packaging Details: | Iron Frame Package |
Delivery Time: | 30 Days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 500 Tons per Month |
Type: | Pressure Parts | Pressure: | Low / High Pressure |
---|---|---|---|
Range Of Applications: | Industrial / Power Station | Specification: | Customized |
Condition: | New | Surface Treatment: | Painted |
Style: | Horizontal And Vertical | Packing: | Iron Frame Package |
High Light: | Recuperative Superheater Coil,Power Station Superheater Coil,Utility reheater 0Coil |
Utility / Power Station Recuperative Boiler Air Preheater Heat Preservation High Efficiency/power plant boiler
Description
Fossil fuel power plants often have a superheater section in the steam generating furnace.The steam passes through drying equipment inside the steam drum on to the superheater, a set of tubes in the furnace. Here the steam picks up more energy from hot flue gases outside the tubing, and its temperature is now superheated above the saturation temperature.
Function
Superheater is to increase the temperature of the steam above its saturation point.
Reheater is basically a superheater that superheats steam exiting the high-pressure stage of a turbine. The reheated steam is then sent to the low-pressure stage of the turbine. By reheating steam between high-pressure and low-pressure turbine it is possible to increase the electrical efficiency of the power plant cycle beyond 40%.The reheat cycle is used in large power boilers since it is feasible economically only in larger power plants.
Certification
Features
1. As the flue gas across tube, the flue gas side of the heat capacity of exile to strengthen, under the same heat transfer coefficient, wall temperature vertical preheater than ordinary steel increased 10-30 Degree Celsius, the overall heat transfer coefficient of about 20.3-24.2W;
2. Two horizontal sealing tube box, the sealed tube box structure welded high strength, pipe damaged or the overall change can only block, and heat-packing seal, can only replace the damaged pipe tube, easy maintenance.
3. The tube air preheater is mainly used for boiler preheater, the low temperature.
Company Introduction
Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
1. Fabrication area of 200,000 square meters
2. 150 Engineers
3. 600 Coded welders
4. 60 Licensed Inspectors(NDT Level-III instructors)
5. Class-A Licenses for Design and Manufacture Boiler
6. ISO 9001:2008 Quality System
7. ASME Certificate of Power Boilers
8. ASME 'S','U' and NB stamp authorization
