| Place of Origin: | Zhangjiagang,China |
| Brand Name: | HD BOILER |
| Certification: | ISO9001,ASME,Grade A,SGS,EN |
| Model Number: | DZL |
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Seaworthy Packing for exporting |
| Delivery Time: | 60-120 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 25 Sets / Year |
| Structure: | Non Steel Frame, Fully Enclosed | Fuel: | Coal - Fired |
|---|---|---|---|
| Size: | Customized | Type: | Natural Circulation |
| Usage: | Industrial | Style: | Vertical |
| High Light: | Thermal Steam Hot Water Boiler,HDB Steam Hot Water Boiler,HDB Hot Water Steam Boiler |
||
Thermal Efficiency Steam Hot Water Boiler Corner Tube Fully Enclosed Structure
• The corner tube boiler water structure is earthquake resistant,due to its non steel-frame.The body weight is supported by the membrane wall and the down comer.The membrane walls are welded into one,creating a shock resistant structure.
• The fully enclosed structure:membrane water-wall boiler by welding together four weeks.
Specifications(Hot-water Boiler)
|
Model(DHL) |
14-AP |
29-AIII |
29-AIII |
29-AIII |
29-AIII |
29-AIII |
46-AIII |
|
Heat |
14 |
29 |
29 |
29 |
29 |
29 |
46 |
|
Work Pressure (Mpa) |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
|
Out/feed Water Tem. |
130/70 |
130/70 |
130/70 |
130/70 |
130/70 |
130/70 |
130/70 |
|
Grate (m2) |
32 |
32 |
32 |
32 |
37 |
37 |
60 |
|
Design Efficiency(%) |
82 |
82 |
82 |
80 |
82 |
80 |
82 |
|
Air perheater |
Yes |
Yes |
Yes |
Yes |
No |
Yes |
No |
|
Size (L×W×H) |
12×8×13 |
14×9×13 |
15×9×13 |
14×10.5×13 |
12.2×9×13 |
14×10.5×13 |
12.2×13.2×15 |
|
Airflow |
29540 |
58570 |
58570 |
58570 |
52161 |
58570 |
117220 |
|
Pressure |
3840 |
3840 |
3840 |
3840 |
2813 |
3840 |
2664 |
|
Motor power |
45 |
90 |
90 |
90 |
55 |
90 |
132 |
|
Speed |
1450 |
1450 |
1450 |
1450 |
1450 |
1450 |
730 |
|
Airflow |
50150 |
97777 |
97777 |
97777 |
97777 |
97777 |
211470 |
|
Pressure |
4008 |
4008 |
4008 |
4008 |
4008 |
4008 |
3545 |
|
Motor Power |
110 |
185 |
185 |
185 |
185 |
185 |
315 |
|
Speed |
14550 |
1450 |
1450 |
1450 |
1450 |
960 |
960 |
|
Model(DHL) |
46-AIII |
46-AIII |
58-AII |
70-AP |
91-AP |
|
Heat |
46 |
46 |
58 |
70 |
91 |
|
Work Pressure (Mpa) |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
|
Out/feed Water Tem. |
130/70 |
130/70 |
130/70 |
130/70 |
130/70 |
|
Grate (m2) |
60 |
57 |
78 |
93 |
110 |
|
Design Efficiency(%) |
82 |
82 |
83 |
84 |
84 |
|
Air perheater |
No |
No |
No |
No |
No |
|
Size (L×W×H) |
12.2×13.2×15 |
13.6×11.6×15.8 |
17.5×13.5×15.6 |
14.2×15.2×15.6 |
15.3×16.2×16.6 |
|
Airflow |
117220 |
117220 |
122560 |
141170 |
184450 |
|
Pressure |
2664 |
2664 |
2166 |
2474 |
2474 |
|
Motor power |
132 |
132 |
90 |
132 |
185 |
|
Speed |
730 |
730 |
960 |
730 |
960 |
|
Airflow |
211470 |
211470 |
188730 |
254670 |
168800 |
|
Pressure |
3545 |
3545 |
4583 |
3290 |
3270 |
|
Motor Power |
315 |
315 |
355 |
355 |
200 |
|
Speed |
960 |
960 |
960 |
960 |
1450 |
Fuel:Bagasse, Biomass, Lignite, Coal,Bituminous coal, Scaly Bark, Fuel gas, Industrial waste, khuff gas, MFO(marine fuel oil), Organic matter, Oil, Litter, Rice hulls, Rubberwood, Sludge, Wood, Woodchips.
Company Introduction
Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
