Custom Carbon Steel Industrial Dust Collector Cyclone Separator High Efficiency
Product Details
| Condition: | New | Weight: | Customized |
|---|---|---|---|
| Material: | Carbon Steel,cyclonic Separator | Efficiency: | As Need |
| Main Function: | Industrial Dust Treatment,Removing Industrial Dust | Usage: | Filter Industry Dust,Collect Wood Dust |
| Highlight |
dust collector cyclone separator,dust collector separator |
||
Product Description
Customized Carbon Steel Industrial Cyclone Separator for Dust Collection
What is cyclone separator?
Cyclone separator is a kind of equipment used for separating gas-solid system or liquid-solid system. The working principle is that the solid particles or droplets with large inertia centrifugal force are separated from the outer wall by the rotational motion caused by the tangential introduction of air flow. The main characteristics of cyclone separator are simple structure, high operating flexibility, high efficiency, convenient management and maintenance, and low cost. It is used for collecting dust with diameter of 5-10 micron. It is widely used in pharmaceutical industry. It is especially suitable for the internal separator of fluidized bed reactor under high temperature and pressure conditions, especially for the coarse dust particles and the high dust concentration. It is widely used in industry as a separation equipment.
What are the functions of cyclone separator?
The main function of cyclone separator equipment is to remove solid particle impurities and droplets carried in the conveying gas as far as possible to achieve gas-solid-liquid separation, so as to ensure the normal operation of pipelines and equipment. In the West-East Gas Transmission Project, cyclone separator is an important equipment.
What are the features of HD cyclone separator?
- The main characteristics of cyclone separator are simple structure, high operating flexibility, high efficiency, convenient management and maintenance, and low cost.
- Cyclone separator is used for collecting dust with diameter of 5-10 micron.
- Cyclone separator is widely used in pharmaceutical industry.
- Cyclone separator is especially suitable for the internal separator of fluidized bed reactor under high temperature and pressure conditions, especially for the coarse dust particles and the high dust concentration.
- In order to improve dust removal efficiency and reduce resistance, many types of cyclone separators, such as spiral type, spiral type, bypass type, diffusion type, swirl type and multi-tube type, have been developed.
- The movement of gas and solid particles in a cyclone separator is very complex.
- There are tangential, radial and axial velocities at any point in the cyclone separator, which vary with the radius of rotation.
- Proper gas velocity should be controlled in practice. Experiments show that the separation efficiency is not high because the gas velocity is too small.
- However, the high gas velocity will lead to serious eddy current and backmixing, which will also reduce the separation efficiency.
Wha are the details of cyclone separator?
| 1 | Cyclonic separation is a method of removing particulates from an air, gas or liquid stream, without the use of filters, through vortex separation. |
| 2 | When removing particulate matter from liquids, a hydrocyclone is used; while from gas, a gas cyclone is used. |
| 3 | Rotational effects and gravity are used to separate mixtures of solids and fluids. |
| 4 | The method can also be used to separate fine droplets of liquid from a gaseous stream. |
Why should you choose HD Boiler?
|
|
|
|
|
|
|
|
Hua Dong Boiler Co., Ltd. is a high-tech enterprise specialized in manufacturing boilers. Established in early 1985s, has two manufacturing bases, this company covers 400,000 ㎡ with fixed assets amounting to USD 110,000,000. There are 1100 employees including 150 technicians and 600 coded welders. Hua Dong holds the manufacturing licenses for Grade A boilers and Grade A1&A2 pressure vessels issued by Chinese General Administration of Quality Supervision, Inspection and Quarantine; also it holds the "S" and "U" "NB" stamps issued by American Society of Mechanical Engineers; meanwhile, this Company has passed the certification of ISO9001, SO3834, EN12952 Quality Management System.
How do you contact us?
