Customized Horizontal Electric Steam Hot Water Boilers Environmentally Friendly
Product Details
| Structure: | Water Tube,dual-drum Horizontal Chain Grate,boiler Made From Italy | Usage: | Industrial,steam Heating |
|---|---|---|---|
| Pressure: | High Pressure | Fuel: | Gas-fired |
| Application: | Industrial Production,Machinery Industry | Product Name: | Horizontal Electric Steam Hot Water Boilers |
| Highlight |
industrial hot water boiler,coal fired hot water boiler |
||
Product Description
Environmentally Friendly Customized Horizontal Electric Steam Hot Water Boilers
- Electric hot water boiler is run by power energy,no noise, no pollution,It's ideal without potential safety problems under the condition of atmospheric pressure operation.
- Boiler body is connected to the atmosphere,equipped with expansion tank,without potential safety problems under the condition of atmospheric pressure operation.
- By use of Nichrome Heating Element,high temperature resistance of electric wire more than 1000℃,service life is 5 - 10 times than traditional one,the application of magnesium rod anode technology,it ensures that heating element difficult to form scale,any other product is Incomparable.
- Boiler operation achieves automatic control,automatic adjustment of export water temperature.
1. Compact structure, small installation space, single-floor boiler room, cost-effective infrastructure.
2. Great assembly level, short installation period and inexpensive installation.
3. Sufficient and reasonable heating surface, quick temperature/pressure-rise of boiler, satisfactory productivity and high heating efficiency.
4. Introduce the air with air distribution chambers of grate. All air distribution
Chambers can adjust the air flow independently and grate can be regulated
Stepless speed. Wide range of applicable coals and full combustion.
5. Electric control cabinet is equipped with complete automatic control and
Monitor instruments featuring high automation, safety, reliability and simple
| Model | CLDR | 0.06-85/60 | 0.12-85/60 | 0.17-85/60 | 0.23-85/60 | 0.29-85/60 | |
| Item | Unit | ||||||
| Rated power | MW | 0.06 | 0.12 | 0.17 | 0.23 | 0.29 | |
| Total heat | 104Kcal | 5 | 10 | 15 | 20 | 25 | |
| Rated Working Pressure | MPa | Atmospheric Pressure | |||||
| Input power | KW | 60 | 120 | 180 | 240 | 300 | |
| Input current | A | 90 | 180 | 270 | 360 | 380 | |
| Voltage | V | 380 | 380 | 380 | 380 | 380 | |
| Water pipe Dia. | DN | 50 | 65 | 65 | 65 | 65 | |
| Return pipe Dia. | DN | 50 | 65 | 65 | 65 | 65 | |
| Blowdown valve dia. | DN | 25 | 25 | 25 | 25 | 25 | |
| Overall Dimension | mm |
850×760 ×1320 |
1010×860 ×1600 |
1170×910 ×1820 |
1290×1030 ×1980 |
1480×1180 ×2050 |
|
| Net Weight | Kg | 280 | 420 | 460 | 530 | 790 | |
| Model | CLDR | 0.35-85/60 | 0.47-85/60 | 0.58-85/60 | 0.7-85/60 | 1.05-85/60 | |
| Item | Unit | ||||||
| Rated power | MW | 0.35 | 0.47 | 0.58 | 0.7 | 1.05 | |
| Total heat | 104Kcal | 30 | 40 | 50 | 60 | 90 | |
| Rated Working Pressure | MPa | Atmospheric Pressure | |||||
| Input power | KW | 360 | 480 | 540 | 720 | 1080 | |
| Input current | A | 540 | 720 | 810 | 1080 | 1620 | |
| Voltage | V | 380 | 380 | 380 | 380 | 380 | |
| Water pipe Dia. | DN | 80 | 100 | 100 | 100 | 125 | |
| Return pipe Dia. | DN | 80 | 100 | 100 | 100 | 100 | |
| Blowdown valve dia. | DN | 25 | 25 | 40 | 50 | 50 | |
| Overall Dimension | mm |
1210×1090 ×1820 |
1350×1160 ×1950 |
2130×1350 ×1860 |
2320×1420 ×1960 |
2630×1500 ×2030 |
|
| Net Weight | Kg | 470 | 590 | 1160 | 1560 |
1720 |
|
Hua Dong Boiler Co., Ltd. is a high-tech enterprise specialized in manufacturing boilers. Established in early 1985s, has two manufacturing bases, this company covers 400,000 ㎡ with fixed assets amounting to USD 110,000,000. There are 1100 employees including 150 technicians and 600 coded welders. Hua Dong holds the manufacturing licenses for Grade A boilers and Grade A1&A2 pressure vessels issued by Chinese General Administration of Quality Supervision, Inspection and Quarantine; also it holds the "S" and "U" "NB" stamps issued by American Society of Mechanical Engineers; meanwhile, this Company has passed the certification of ISO9001, SO3834, EN12952 Quality Management System.
