Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler

Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler

MOQ: 1 set
Price: Negotiable
Standard Packaging: Iron Frame Packing
Delivery Period: Negotiation
Payment Method: L/C, T/T, Western Union
Supply Capacity: 20 Sets per Year
Detail Information
Place of Origin
ZHANGJIAGANG,CHINA
Brand Name
HD BOILER
Certification
ISO9001 , SGS , TUV , ASME , EN
Model Number
CFB BOILER
Name:
CFB BOILER
Fuel:
Coal Fired
Burning Style:
Fluidized Bed Furnace
Media:
Steam And Water
HS Code:
3215960855
Usage:
Power Plant
Highlight:

circulating fluidized bed boilers

,

utility boiler

Product Description



Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler



35t/h Environmental Friendly CFB Boiler Coal Fired China Professional Top Quality Industrial Application



Product Description



The circulating fluidized bed (CFB) is a developing technology for coal combustion to achieve lower emission of pollutants. By using this technology, up to 95% of pollutants can be absorbed before being emitted to the atmosphere.

Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler 0

Parameter



Item

Unit

Specification

Model



HD-35/3.82-M

HD-35/5.3-M

Rated evaporation

t/h

35

Rated steam pressure

MPa

3.82

5.3

Rated steam temperature

450

450

Feed water temperature

150

150

Fuel type

Anthracite, lean coal, bituminous coal, lignite, petroleum coke, breeze, etc.

Furnace height

M

22

Furnace section

m2

9.6

Number of coal feeder

Unit

2

Super heater thermostat mode



Spray desuperheater

Unburned carbon

(bituminous coal)

%

<6

Pre-heater air temperature

140

Exhaust gas temperature

145



Characteristics



1. Steel sheet separator cyclone and air-cooled(water cooled )cyclone separator.
2. Tail superheater area using air-cooled(water-cooled)wall enclosure.
3. Rear fender economizer furnace wall: the guard plate frame light furnace wall, boiler tightness.
4. Design of steel structures: Using finite element analysis software of the boiler structure was accurately calculated to ensure that the load distribution is reasonable.
5. Optimizing a secondary air ratio can be reduced auxiliary power, strengthening extension to extend the disturbance in the furnace flue gas residence time, improve thermal efficiency of the boiler.
6. Furnace section play, smoke long residence time in the furnace, the furnace, the furnace up speed is low, the furnace circulating volume, improve the boiler burnout rate, colleagues, greatly reducing the wear of the furnace water wall region.



Certificate



Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler 1

ASME 'S' & 'U' STAMP



Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler 2

NB(National Board)



Company Introduction



Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.



1. Fabrication area of 400,000 square meters

2. 150 Engineers

3. 600 Coded welders

4. 60 Licensed Inspectors(NDT Level-III instructors)

5. Class-A Licenses for Design and Manufacture Boiler

6. ISO 9001:2008 Quality System

7. ASME Certificate of Power Boilers

8. ASME 'S','U' and NB stamp authorization



Environmental Friendly Coal Fired Boiler , Fluidized Bed Combustion Boiler 3
