|Place of Origin:||Zhangjiagang,china|
|Brand Name:||HD BOILER|
|Certification:||ISO9001 , SGS , TUV , ASME , EN|
|Model Number:||Cyclone separator|
|Minimum Order Quantity:||1 Set|
|Packaging Details:||Iron Frame Package|
|Delivery Time:||30- 100 Days|
|Payment Terms:||Western Union, L/C, T/T|
|Supply Ability:||100 sets per Month|
|Name:||Multi Cyclone Separator||Type:||Fabric Dust Collector|
|Material:||Carbon Steel, Alloy Steel, Equivalent||Application:||Boiler System And Industrial System|
dust collector cyclone separator,
dust collector separator
Steel Single High Efficiency Cyclone Dust Collector , Industrial Cyclone Dust Collector
Cyclone Collector are often employed as an Initial Stage Collector to lighten heavy dusts loads before being sent to a Primary Stage Fabric Collector. By removing coarse particles from the gas stream, and allowing later stage Fabric Collectors to solely remove finer particles, these collectors increase the efficiency and service life of Fabric Collectors (Baghouses) and their Filters.
Thus protecting your larger and most costly investment from unnecessary wear and tear.Cyclone Separator or Dust Collector Price for BoilerCyclone Collector are often employed as an Initial Stage Collector to lighten heavy dusts loads before being sent to a Primary Stage Fabric Collector.
A high speed rotating (air)flow is established within a cylindrical or conical container called a cyclone. Air flows in a spiral pattern, beginning at the top (wide end) of the cyclone and ending at the bottom (narrow) end before exiting the cyclone in a straight stream through the center of the cyclone and out the top.
Larger (denser) particles in the rotating stream have too much inertia to follow the tight curve of the stream and strike the outside wall, falling then to the bottom of the cyclone where they can be removed.
|1||Cyclonic separation is a method of removing particulates from an air, gas or liquid stream, without the use of filters, through vortex separation.|
|2||When removing particulate matter from liquids, a hydrocyclone is used; while from gas, a gas cyclone is used.|
|3||Rotational effects and gravity are used to separate mixtures of solids and fluids.|
|4||The method can also be used to separate fine droplets of liquid from a gaseous stream.|
In a conical system, as the rotating flow moves towards the narrow end of the cyclone the rotational radius of the stream is reduced, separating smaller and smaller particles.
Cyclonic separation can eliminate particulates, such as dirt and dust, from a stream of air, gas or liquid. Engineers sometimes call these tornadic dust busters centrifugal separators. That's because at the root of these machines is something called centrifugal force.
|1||Although there are four commonly used cyclone separators, their operating principles based on that of the conventional cyclone, are very similar.|
|2||In the conventional cyclone, the gas enters a cylinder tangentially, where it spins in a vortex as it proceeds down the cylinder.|
|3||A cone section causes the vortex diameter to decrease until the gas reverses on it and spins up the center to the outlet pipe or vortex finder.|
|4||A cone causes flow reversal to occur sooner and makes the cyclone more compact Dust particles are centrifuged toward the wall and collected by inertial impingement.|
|5||The collected dust flows down in the gas boundary layer to the cone apex where it is discharged through an air lock or into a dust hopper serving one or more parallel cyclones .|
|6||Although conventional cyclones can be built to larger diameter, they are commonly 600 to 1600 mm in diameter.|
1. Low capital cost.
2. Ability to operate at high temperatures.
3. Can handle liquid mists or dry materials.
4. Low maintenance requirements (no moving parts).
5. Small footprint - requires relatively small space.
