Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001

Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001

  • Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001
  • Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001
  • Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001
  • Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001
Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001
Product Details:
Place of Origin: China
Brand Name: HD Boiler
Certification: ISO9001,ASME,Grade A,SGS,EN
Model Number: WNS
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: Seaworthy Packing
Delivery Time: 30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Sets / Per Year
Contact Now
Detailed Product Description
Condition: New Structure: Fire Tube
Fuel Available: Gas-Fired, Oil-Fird, Diesel-Fired Rated Working Pressure(Mpa): 1.0-1.25
Evaporation Capacity: 1-20t / H Rated Steam Temperature: 184-193
Surface Treatment: Painted Operation: Automatic
Typical User: Food And Textile And Hotel And Oil Fired Placemen: Horizontal Boiler
High Light:

industrial steam boiler

,

coal fired hot water boiler



Fast start WNS OIL(GAS) Fired Steam Hot Water Boiler Small Footprint with ISO9001



 Structural features


1, WNS series boiler adopts horizontal three return wet back liner structure is a corrugated furnace, Mainly by the pot shell, furnace, steering smoke room, smoke tube etc.

2, Boiler suitable for light oil, heavy oil, natural oil, liquefied petroleum gas, city gas and other fuels.

The performance advantage




  • Use the wet liner structure, furnace heating surface wave back, symmetrical layout, effectively reduce the thermal stress, improves the safety and life of the boiler.
  • Using the thread smoke tube to improve the heat transfer effect of flue pipe.
  • Boiler heating surface layout reasonable, high thermal efficiency, fast start.
  • The steam boiler combustion chamber adopts low position, so that the boiler water level safety range is larger, the boiler steam is larger, the steam quality is well guaranteed.
  • Using the international well-know brand burner and advanced automatic control system, the combustion is more stable, more convenient operation, operation more safety.
  • Boiler structure is compact, small footprint, fast installation.



Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001 0



Parameter



Model WNS
2-1.0-Y,Q
WNS
4-1.25Y,Q
WNS
6-1.25-Y,Q
WNS
8-1.25-Y,Q
WNS
10-1.25-Y,Q
WNS
15-1.25-Y,Q
WNS
20-1.25-Y,Q
Rated evaporation capacity(t/h) 2 4 6 8 10 15 20
Rated working pressure(MPa) 1.0 1.25 1.25 1.25 1.25 1.25 1.25
Rated steam temperature 184 193 193 193 193 193 193
Wear-supply temperature 20 20 60 60 60 104 104
Boiler volume(m3) 3.2 7.4 10.6 11.7 14.4 16.8 21.2
Design efficiency(%) 90 90 90 90 90 90 90
Applicable fuel



Light oil,heavy oil,natura gas,liquified gas and urban coal gas

Extemal size Lenght A(mm) 5084 6022 7151 7600 8360 9050 9650
Width B(mm) 2450 2700 2800 3000 3000 4500 5000
Height H(mm) 2380 2684 2882 3200 3200 5200 5600
Boiler weight (t) 7.2 12.6 17.2 18.6 23.5 36.2 45.5
Diamater of main steam opening(mm) 65 100 125 150 150 200 200
Diameter of safety valve(mm) 40×2 50×2 65×2 65×2 80×2 100×2 100×3
Chimney diamater(mm) 350 450 600 700 750 900

1000



Company Introduction


Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
