| Place of Origin: | CHINA |
| Brand Name: | HD Boiler |
| Certification: | ISO9001,ASME,Grade A,SGS,EN |
| Model Number: | Thermal Oil Boiler |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Seaworthy packing |
| Delivery Time: | 50 days |
| Payment Terms: | T/T, L/C, Western Union, D/P, MoneyGram |
| Supply Ability: | 500 sets per year |
| Usage: | Industrial,Crude Oil Thermal Recovery | Type: | Natural Circulation,Once Through |
|---|---|---|---|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Output: | Steam,hot Conduction Oil |
| Application: | Industrial Production | Material: | Special Boiler Steel Plate |
| High Light: | ASME Thermal Oil Boiler,ASME Heating Oil Boiler |
||
Natural Circulation Industrial Thermal Recovery for Crude Oil Thermal Recovery
Description
Flame and high temperature smoke produced by complete burning of fuel (light diesel oil,heavy oil,residual oil,natural gas,liquefied petroleum gas,city gas etc.) exchange heat with organic heat transfer media in the pipe by radiative transfer and convection transfer, at the same time, the organic heat transfer media is circulating in the system pushed by the pump. And then the using-heat equipment takes heat from the media, which goes back to the boiler after heat exchange. So it is an organic heat circulation system.
Details
| Fuel: | Gas , Oil Fired | Pressure: | Low Pressure |
|---|---|---|---|
| Place Style: | Vertical | Media: | Organic Heat Transfer Material |
| Usage: | Industrial | Specification: | Customized |
| Surface Treatment: | Painted | Port: | Shanghai |
Parameter
|
Model YYL(W) |
350 Y(Q) |
600 Y(Q) |
900 Y(Q) |
1200 Y(Q) |
1500 Y(Q) |
1800 Y(Q) |
2300 Y(Q) |
2900 Y(Q) |
3500 Y(Q) |
||
| Rated power(kw) | 350 | 600 | 900 | 1200 | 1500 | 1800 | 2300 | 2900 | 3500 | ||
| Heat supply×104(kCal/h) | 30 | 50 | 75 | 100 | 160 | 150 | 200 | 250 | 300 | ||
| Thermal efficiency(%) | ≥88 | ≥88 | ≥88 | ≥88 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ||
| Design pressure(MPa) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | ||
| Maximum working temperature(℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | ||
| Medium circulation rate(m3/h) | 40 | 58 | 100 | 100 | 100 | 160 | 160 | 200 | 200 | ||
| The furnace medium capacity(m3) | 0.4 | 0.6 | 0.6 | 0.8 | 1.2 | 2.1 | 2.6 | 3.5 | 7.8 | ||
| Competent diameter(DN) | 100 | 100 | 125 | 125 | 125 | 150 | 150 | 200 | 200 | ||
| Capacity(kw) | 14.5 | 18 | 31 | 37.5 | 49.5 | 57.5 | 61.5 | 75 | 75 | ||
| Applicable fuel | Oil,Gas | ||||||||||
| Fuel consumption Kg/h(oil) | 34 | 56 | 84 | 111 | 141 | 163 | 217 | 273 | 326 | ||
|
Dimensions (￠·H)m |
Vertical oil furnace | 1.3×2.5 | 2×3.5 | 2.1×3.5 | 2.2×3.5 | 2.2×4 | 2.2×4.4 | 2.7×5.1 | 2.8×6.5 | 3.2×6.7 | |
|
Circulation pump |
Model WRY | 80-50-180 |
100- 65-190 |
100- 65-230 |
100- 65-240 |
100- 65-257 |
125- 80-250 |
125- 80-250 |
125- 100-250 |
125-100-250 | |
| Flow(m3/h) | 40 | 60 | 100 | 100 | 100 | 160 | 160 | 200 | 200 | ||
| Lift(m) | 40 | 38 | 55 | 70 | 80 | 60 | 60 | 60 | 60 | ||
| Power(kw) | 7.5 | 11 | 22 | 30 | 37 | 45 | 45 | 55 | 55 |
||
Features
1. Energy efficient
2. Safe and reliable
3. Easy to install
4. Fuel applicable
5. Application industry
Company Information
Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
1. Fabrication area of 200,000 square meters
2. 150 Engineers
3. 600 Coded welders
4. 60 Licensed Inspectors(NDT Level-III instructors)
5. Class-A Licenses for Design and Manufacture Boiler
6. ISO 9001:2008 Quality System
7. ASME Certificate of Power Boilers
8. ASME 'S','U' and NB stamp authorization
