CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers

CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers

    • CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers
    • CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers
    • CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers
    • CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers
  • CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers

    Product Details:

    Place of Origin: JIANGSU, CHINA
    Brand Name: HD Boiler
    Certification: ISO9001 , SGS , TUV , ASME , EN
    Model Number: H FIN TUBE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Delivery Time: 30 DAYS
    Contact Now
    Detailed Product Description
    Type: Fin Tube,Heat Exchanger Tube Application: Heater Parts,Heat Exchanger
    Tube Material: Stainless Steel,Carbon Steel,Alloy Steel Product Name: H FIN TUBE
    Material: CS / ND / Stainless Steel Circulation: Natural



    Boiler Pressure Parts CS/ND/Stainless Steel Boiler Fin Tube Heat Exchanger For Coal-fired Boiler Economizers





    Product Description



    Finned tube is used to recover heat from flue gas exhaust of power plant boilers, industrial boilers, industrial kilns and marine power plants, make full use of waster heat, save energy, protect environment and reduce emissions, and improve fuel utilization rate, they are the strengthened heat exchange elements arranged at the tail of the fuel duct of the system.



    There are spiral finned tubes and H-type finned tubes. Spiral finned tubes can further divided into high frequency resistance welding spiral finned tube, brazed spiral finned tube and integral spiral finned tube.

    CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers



    Spirial Finned Tube:



    Spiral finned tubes are widely used in heat recovery of boiler economizer, air preheater, and waste heat boiler, as well as heat exchange equipment in chemical industry, pressure vessel and other fields. The capacity of units used in boilers has also increased from small to large, and their applications are increasing day by day. At present, many professional manufacturers in China can produce high frequency resistance welding, brazing spiral finned tubes, and the production equipment and technology of finned tubes have been developed, designed and manufactured from importation, digestion and absorption to self-development. The quality has reached the requirements of advanced foreign standards.

    Advantages of using finned tubes:

    1. the heat transfer area is increased in the effective space to improve the heat transfer effect.

    2. Reduce the occupancy space of heat transfer surface and reduce its volume, especially for fast-loading boilers.

    3. Reduce the equipment cost and improve the safety of equipment.

    4. Due to the decrease of water side pressure drop, the operation cost is reduced.

    5. The stiffness of finned tubes are increased, and the seismic resistance of the tube is improved.



    H-type Finned Tube:



    Product Description:

    H type finned tube is used to recover waster heat from flue gas exhaust of power plant boilers, industrial boilers, industrial kilns and marine power plant, make full use of waste heat, save energy and reduce emission to protect environment, improve fuel utilization rate, and they are the strengthened heat exchange elements arranged at the tail of the fuel duct of the system.



    The utility model relates to a double H-type finned tube strengthened heat exchange element, which is characterized by:

    • the fins are butt welded on the surface of the steel tube
    • The contact of the fin welded parts adopts multiple zigzag shapes, the heating surface is is welded uniformly and firmly, the welding angle is formed uniformly and the surface is smooth, there is no slag inclusion pore weld, and the penetration rate reaches 97%.

    CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers



    Technical parameter

    Medium air, flue gas, thermal oil, water, brine, refrigerant, etc.
    Temperature standard heat exchanger to 560 ° C by special materials can be higher
    Pipe materials carbon steel, stainless steel, alloy or special materials
    Ribs materials carbon steel, stainless steel, non-ferrous metal, alloy or special materials
    Thermal insulation &Surface treatment according to customers specification

    CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers

    Features



    1. The equipment body can be designed into many modules to ensure the long term and stable running;

    2. Compact structure which can enlarge the heat exchanging area in order to add the heat transfer area and less leakage

    3. Improve the heat transfer efficiency

    4. Structure arrangement: In line or staggered arrangement





    Quality Control



    1 Impact test and Strength calculation report with applied materials information.
    2 100%NDT(non-destructive inspection) report of steel plate, tube and electrode.
    3 X-ray, γ-ray and liquid penetrant test inspection report (welding seam): to ensure the quality of the entire boiler.
    4 Hydraulic test report: ensure the standard working pressure and safety.






    CS / ND / Stainless Steel Boiler Fin Tube Heat Exchanger For Boiler Economizers



    Company Introduction


    Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
