Naturally Circulated High Pressure Heat Recovery Generator For Industry

Naturally Circulated High Pressure Heat Recovery Generator For Industry

  • Naturally Circulated High Pressure Heat Recovery Generator For Industry
  • Naturally Circulated High Pressure Heat Recovery Generator For Industry
  • Naturally Circulated High Pressure Heat Recovery Generator For Industry
  • Naturally Circulated High Pressure Heat Recovery Generator For Industry
Naturally Circulated High Pressure Heat Recovery Generator For Industry
Product Details:
Place of Origin: China
Brand Name: HDB
Certification: SGS , ASME , ISO9001 , EN , CE
Model Number: HRSG Heat Recovery Steam Generator
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Seaworthy packing
Delivery Time: 30~50days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 tons per month
Contact Now
Detailed Product Description
Type: Natural Circulation Usage: Industry And Power Station
Style: Horizontal,Vertical Pressure: Low / Intermediate / High Pressure
Condition: New Weight: Customized
High Light:

waste heat recovery boiler

,

industrial boilers and heat recovery steam generators



Naturally Circulated High Pressure Heat Recovery Generator For Industry



♢What is HRSG?



  • HRSG, as the name implies, refers to a boiler that uses various waste gases, waste materials, waste heat in waste gas or waste heat and the heat generated by combustion of combustible materials to heat water to a certain temperature. An oil-fired boiler, a gas-fired boiler, and a coal-fired boiler having a smoke box and a flue heat recovery are also referred to as a waste heat boiler, and the waste heat boiler can produce hot water or steam through waste heat recovery to be supplied to other sections.



♢What is the working principle of HRSG?



  • The combustion of fuel oil, gas and coal produces high-temperature flue gas to release heat. The high-temperature flue gas enters the furnace chamber first, then enters the waste heat recovery device in the front smoke box, then enters the pyrotechnical pipe, and finally enters the waste heat recovery device in the flue pipe of the rear smoke box.
  • The high-temperature flue gas turns into low-temperature flue gas and is discharged into the atmosphere through the chimney.Because the waste heat boiler greatly improves the utilization rate of the heat released by fuel combustion, this kind of boiler is very energy-saving.



♢What are the advantages of HRSG?



Kiln (AQC) HRSG Features Kiln (SP) HRSG Features
1.Modular assembly structure, reliable sealing expansion 1. Heating surface tubes and headers with privildged connection structure, reducing mechanical shock and vibration
2. Adopt wear fin tubes, boiler pressure parts life assurance 2. By mechanical vibration cleaning mode, continous cleaning mode little impact on system operation
3.Unique flash technology, the boiler outlet temperature is reduced to below 90ºC 3.Set sealed scraper gray machine, greatly reducing dust tail.



♢What are the parameters of HRSG?



Cement production line capacity t/d 1000 2500 5000 10000
Boiler inlet flow Nm3/h Kiln(front) 60000 88000 243000 472000
Kiln(tail) 76000 170000 328000 612000
Boiler inlet gas temperature℃ Kiln(front) 370 360 380 390
Kiln(tail) 360 320~360 330 330
Rated evaporation t/h Kiln(front) 5.8 7.25 24 50
Kiln(tail) 7.5 10~15.8 20~24.6 35.5
Rated steam pressure Mpa Kiln(front) 1.25 1.25 1.25 1.25
Kiln(tail) 1.25 1.25 1.25 1.25
Rated steam temperature℃ Kiln(front) 340 330 350 360
Kiln(tail) 340 300~340 310 310
Boiler structure Kiln(front) Vertical Vertical Vertical Vertical
Kiln(tail) Vertical Vertical and Horizontal Vertical and Horizontal Vertical



♢Why do you choose HDB?




Hua Dong Boiler Co., Ltd. is a high-tech enterprise specialized in manufacturing boilers. Established in early 1985s, has two manufacturing bases, this company covers 400,000 ㎡ with fixed assets amounting to USD 110,000,000. There are 1100 employees including 150 technicians and 600 coded welders.



Hua Dong holds the manufacturing licenses for Grade A boilers and Grade A1&A2 pressure vessels issued by Chinese General Administration of Quality Supervision, Inspection and Quarantine; also it holds the "S" and "U" "NB" stamps issued by American Society of Mechanical Engineers; meanwhile, this Company has passed the certification of ISO9001, SO3834, EN12952 Quality Management System.





Some Pictures



Naturally Circulated High Pressure Heat Recovery Generator For Industry 0Naturally Circulated High Pressure Heat Recovery Generator For Industry 1



Naturally Circulated High Pressure Heat Recovery Generator For Industry 2
