Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard

Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard

    • Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard
    • Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard
    • Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard
  • Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard

    Product Details:

    Place of Origin: ZhangJiaGang,JiangSu ,China
    Brand Name: HD BOILER
    Certification: ISO9001 ,SGS , TUV, ASME , EN
    Model Number: Fin Tube

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set / Sets 10tons
    Price: Negotiable
    Packaging Details: Standard Seaworth Package
    Delivery Time: 50-100days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 500ton / Month
    Contact Now
    Detailed Product Description
    Condition: New Structure: Fir / Water Tube
    Fuel: Coal / Gas / Coal-fired / Water Heat Type: Boiler Part
    Pressure: Low / High Pressure Range Of Application: Industry Boiler Power Plant Boiler
    Specification: Customized Surface Treat: Painted
    Technology: High-frequency Welding HS Code: 3215960855





    Energy Efficient Boiler H-Fin Tube , Extruded For Economizer ASME Standard



    Company Information


    HD Boiler established in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd. (trading as HD Boiler), is a professional industrial manufacturer, producing utility boiler,industrial boiler,HRSG boiler and all kinds of boiler parts, such as waterwall panels, economizers, air preheaters, superheaters, headers, spiral fin tubes, H-fin tubes, heat pipes etc. HD Boiler is located in Dong Lai Industrial Park, east suburb of Zhang Jia Gang City. The plant’s location is around 150km Expressway to Shanghai Port or 60km State Road to Suzhou or Wuxi, with transportation extending in all directions conveniently and quickly.



    Product Description


    H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer, which has high efficiency,little resistance,less wear and light weight.


    Our products can be modified according to our customers' needs and the situation.we design and manufacture safe,reliable and efficient H-fin tubes.HD BOILER has also completed stand-alone product quality assurance systems.Production of H-fin tubes are with high heat transfer efficiency, they have flue gas resistance and are designed for a small space.
    Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard

    Parameter

    Technical parameters The high degree of fin 0-16mm(or outside diameter of fin φ25-φ75);
    Pitch of fins 2.0-5.0mm; Length of finning tube 0.5~ 14m.
    Single metal rolling finning tube Pure aluminum 1060 or aluminum alloy 6063,6061.
    Outside diameter Shall be less than 40mm
    Double metal rolling finning tube Tube-based protection from the outer layer of aluminum
    tubes,corrosion-resistant,Tube-based can be made of carbon steel pipe,in addition to,stainless
    steel tube and copper tube can also be used, as well as titanium alloy tube
    Package The aluminum finned tubes are well packed in plastic film in the inner and steel fram
    in the outer





    PRODUCT TYPE TUBE MATERIAL FIN MATERIAL TUBE SIZE FIN SIZE
    Heat Exchanger Finned Tube Extruded Fin Tube All Kind of Material can be applied Aluminum A1100 15.88~50.8 7~11.5FPI
    Fin Height Max 16mmH
    L-Foot Fin Tube All Kind of Material can be applied Copper C1100, C1220 12.70~50.8 7~11.5FPI
    (Wrap On Type) Fin Height Max 16mmH
    G-Fin Tube (Embedded Type) Aluminum A1100, A1050, A1060
    High Frequency Welded Finned Tube A179 Carbon Steel Tube Carbon Steel Tube 12.70~160 1.5~7FPI
    Stainless Steel Tube Stainless Steel Tube 0.8~3.2mm. Thickness
    Alloy Steel Material Alloy Steel Material
    Integral Copper & Copper Alloy High Finned Tube C12200, C11000, C70600 C12200, C11000, C70600 15.88~22.23 5~9FPI
    Max 12mm. H
    Oval Finned Tube Carbon Steel Tube Carbon Steel Tube All Size Available 5~15FPI
    Stainless Steel Tube Stainless Steel Tube
    Alloy Steel Material Alloy Steel Material
    Copper & Copper Alloy Tube Copper & Copper Alloy Tube
    Monometallic Fin Tube Low Fin Tube Carbon Steel, stainless steel, titanium, copper, brass, nickel alloy, etc. -- 9.52~40 12, 16, 19 28 FPI, etc.
    Turbo-C Tube
    Turbo-E Tube
    Corrugated Tube All Kind of Material -- 6.35~40 2~9FPI



    Energy Efficient Boiler H - Fin Tube Extruded For Economizer ASME Standard
